GPF-300P
SMART SERIES
![80 PLUS BRONZE](https://www.chieftec.eu/upload/img/c-product_icon1210330182429_8741.jpg)
![Bulk](https://www.chieftec.eu/upload/img/c-product_icon1210331182316_7977.jpg)
OVERVIEW
A strong GPF power supply unit in TFX format with the latest ATX 2.3 specification and active PFC that is compatible with Intel as well as with AMD CPUs.
SPECIFICATIONS
![CE](https://www.chieftec.eu/upload/img/c-product_icon2201130170659_9036.png)
![CB](https://www.chieftec.eu/upload/img/c-product_icon2201130170718_4334.png)
![EAC](https://www.chieftec.eu/upload/img/c-product_icon2201130170739_3704.png)
![interseroh](https://www.chieftec.eu/upload/img/c-product_icon2201231182818_7480.jpg)
![Recycle](https://www.chieftec.eu/upload/img/c-product_icon2210107174335_4189.jpg)
![RoHS](https://www.chieftec.eu/upload/img/c-product_icon2201130170844_9436.png)
![ErP](https://www.chieftec.eu/upload/img/c-product_icon2201130170907_1075.png)
![WEEE](https://www.chieftec.eu/upload/img/c-product_icon2201130170942_3172.png)
![E](https://www.chieftec.eu/upload/img/c-product_icon2201130170818_9523.png)
![TUV](https://www.chieftec.eu/upload/img/c-product_icon2201130170639_8801.png)
![FCC](https://www.chieftec.eu/upload/img/c-product_icon2201231182745_4879.jpg)
Model | Smart 300W |
---|---|
Article no. | GPF-300P |
EAN code | 4710713234666 |
Weight (without/with package) | 1.07 kg / 1.13 kg |
AC Input | 100 - 240V / 6.3A |
Frequency | 47 - 63Hz |
+5V | 16A |
+3,3V | 15A |
+5V & +3,3V combined | 95W |
+12V1 | 14A |
+12V2 | 15A |
+12V1, +12V2 combined | 276W |
P.F. | >0,9 |
-12V | 0,3A / 3,6W |
+5VSB | 2,0A / 10W |
Maximum Power | 300W |
20+4 PIN ATX | 1 |
---|---|
8 PIN EPS(4+4) | 1 |
8 PIN PCIe (6+2) | |
SATA | 4 |
MOLEX/FLOPPY | 2/1 |
20+4 PIN ATX | 300 |
---|---|
8 PIN EPS(4+4) | 350 |
8 PIN PCIe (6+2) | |
SATA | 2 x 350/150 |
MOLEX/FLOPPY | 350/150/150 |
ATX12V Version | ATX 12V 2.3 |
---|---|
Efficiency | 80+Bronze |
Dimension (DxWxH) | 175 mm x 86 mm x 65 mm |
PFC | Active PFC (0,9) |
Fan | 80mm silent fan |
Security | AFC (Automatic Fan speed Control) OPP (Over Power Protection) OVP (Over Voltage Protection) SCP (Short Circuit Protection) SIP (Surge & Inrush Protection) UVP (Under Voltage Protection) |
Warranty | 24 Months |
